Eco-Guard™ Series 70 Architectural Fixed Window
The Series 70 Architectural Fixed Window is built for fixed openings and architectural shapes with Large Missile approval.
Preview configurations, frame colors, and glass colors. Visualice configuraciones, colores de marco y colores de vidrio.
The visualizer uses the image combinations generated from this model’s configuration, frame color, and glass color options. El visualizador usa las combinaciones de imágenes generadas por configuración, color de marco y color de vidrio.
Product Visualizer Visualizador de Producto
Eco-Guard™ Series 70 Architectural Fixed Window
A Florida Product Approved fixed window available in a wide range of architectural shapes.
Frame Color Color de Marco
Glass Color Color de Vidrio
Image updates when you select a configuration, frame color, or glass color. La imagen cambia al seleccionar configuración, color de marco o color de vidrio.
Product Details Detalles del Producto
Eco-Guard™ Series 70 Architectural Fixed Window
The Series 70 Architectural Fixed Window is built for fixed openings and architectural shapes with Large Missile approval.
Selected Detail Detalle Seleccionado
Features
- Heavy-gauge aluminum T6 alloy
- Stainless steel assembly screws
Selected Detail Detalle Seleccionado
Dimensions & Performance
- 2 1/8" frame depth
- Maximum width: 60"
- Maximum height: 104"
- Maximum size: 32" x 104"
- Design pressure: +60/-60 psf
Selected Detail Detalle Seleccionado
Additional Features
- 5/16" HS/HS glass
- Glass colors include Clear, Gray, Bronze, Green, Azuria, and Obscure with White interlayer
- Florida Product Approval: Large Missile
Selected Detail Detalle Seleccionado
Options
- Energy efficient LoE coatings
- Extruded double-applied 1" colonial muntins
- Architectural shapes
Product Selection Support Ayuda para Seleccionar Producto
Need to confirm if this model fits your opening? ¿Necesita confirmar si este modelo funciona para su abertura?
Send us the opening size, project location, preferred glass color, frame color, and any HOA or building requirements. We can help verify the right model and installation approach. Envíenos el tamaño de la abertura, ubicación del proyecto, color de vidrio, color de marco y requisitos de HOA o edificio. Podemos ayudarle a verificar el modelo y la instalación adecuada.
Impact-rated guidance Guía para impacto
We help match the model, glass package, and installation needs for your project. Le ayudamos a elegir modelo, paquete de vidrio e instalación para su proyecto.
Visual options Opciones visuales
Frame color, glass color, and configuration combinations are ready for client previews. Las combinaciones de marco, vidrio y configuración están listas para visualizar.
