Eco-Guard™ 450 Frontset Storefront Window
The 450 Frontset Storefront Window is a commercial impact system with internally wet glazed construction, double weatherstripping, and steel reinforcement options.
Preview configurations, frame colors, and glass colors. Visualice configuraciones, colores de marco y colores de vidrio.
The visualizer uses the image combinations generated from this model’s configuration, frame color, and glass color options. El visualizador usa las combinaciones de imágenes generadas por configuración, color de marco y color de vidrio.
Product Visualizer Visualizador de Producto
Eco-Guard™ 450 Frontset Storefront Window
A commercial storefront impact window with a 4-inch frame depth and +80/-90 psf maximum design pressure.
Frame Color Color de Marco
Glass Color Color de Vidrio
Image updates when you select a configuration, frame color, or glass color. La imagen cambia al seleccionar configuración, color de marco o color de vidrio.
Product Details Detalles del Producto
Eco-Guard™ 450 Frontset Storefront Window
The 450 Frontset Storefront Window is a commercial impact system with internally wet glazed construction, double weatherstripping, and steel reinforcement options.
Selected Detail Detalle Seleccionado
Features
- 9/16" HS/HS glass with PVB
- 1 3/4" x 4" deep system
- Double weatherstripping
- Stainless steel assembly screws
- Extruded aluminum snap-on glazing beads
- Internally wet glazed
Selected Detail Detalle Seleccionado
Dimensions & Performance
- Maximum width: 60 3/4" at 90" frame height
- Maximum height: 108" at 42 3/4" width
- Florida Product Approval
- Maximum pressure design: +80/-90 psf
Selected Detail Detalle Seleccionado
Options
- 1 3/16" insulated laminated glass
- 9/16" heat strengthened laminated glass with SG
- Steel reinforcement
Product Selection Support Ayuda para Seleccionar Producto
Need to confirm if this model fits your opening? ¿Necesita confirmar si este modelo funciona para su abertura?
Send us the opening size, project location, preferred glass color, frame color, and any HOA or building requirements. We can help verify the right model and installation approach. Envíenos el tamaño de la abertura, ubicación del proyecto, color de vidrio, color de marco y requisitos de HOA o edificio. Podemos ayudarle a verificar el modelo y la instalación adecuada.
Impact-rated guidance Guía para impacto
We help match the model, glass package, and installation needs for your project. Le ayudamos a elegir modelo, paquete de vidrio e instalación para su proyecto.
Visual options Opciones visuales
Frame color, glass color, and configuration combinations are ready for client previews. Las combinaciones de marco, vidrio y configuración están listas para visualizar.
Compare related window models. Compare modelos relacionados.
Review other models in the same window family before making a final selection. Revise otros modelos de la misma familia antes de tomar una decisión final.
